Electronic Robot Kits


A series of Robot Kits for the future engineer. Build these kits and find out how much fun electronics & mechanics can be !
A sensor-activated robot car. The car changes directions when the sensor detects noise or when the car hits an object.

Specifications

  • uses a microphone as sound sensor

  • dimensions: 110 x 90 x 60mm

  • power supply: 2 1.5V AA batteries (not included)

PRICE: $25.20

Robot Car
(KSR1)

Robot Frog
(KSR2)




The robot frog moves forward when it detects sound and repeats the following movements sequentially :
start (move forward) -> stop -> left turn -> stop -> right turn -> stop. Two sets of gear motors (unassembled).

  • dimensions: 90 x 125 x 100mm

  • power supply:

    • mechanical: 2 1.5V AA batteries (not included)

    • electronic: 9V-battery (not included)

$31.80

"Escape" Robot Kit
(KSR4)

The Escape Robot Kit works just like an A.I. robot. It never fails to find its way out of a maze. The Escape Robot uses 3 IR emitting diodes and 1 IR receiving module to send and receive signals and detect obstacles.
The Escape Robot's built-in microprocessor enables it to "think" on its own: it gathers and processes information on its environment so it can avoid any obstacle. The Escape Robot moves about on 6 legs.
This kit comes complete with 2 sets of differently designed legs that move in their own distinct way.

  • dimensions: 140 x 150 x 100mm

$37.95

Scarab is a robot that uses 2 touch sensors to detect obstacles. When its antennas (touch sensor) detect an obstacle, Scarab will first step back and then automatically execute a two-step manoeuvre to avoid the obstacle. The manoeuvre is a combination of "left turn", "right turn", "reverse" or "stop". The Scarab Robot can be configured with different sets of movements.
The Kit comes complete with 2 sets of differently designed legs, which move in their own distinct way.

  • dimensions: 175 x 145 x 85mm

$37.95

"Scarab" Robot Kit
(KSR5)

"Ladybug" Robot Kit
(KSR6)

The Ladybug Robot walks on 6 legs and uses infrared emitting diodes for "eyes" in order to avoid obstacles. Ladybug walks straight ahead but automatically makes a left turn the moment an obstacle is detected.
The Kit comes complete with 2 sets of differently designed legs, which move in their own distinct way.

  • dimensions: 120 x 150 x 85mm (length feelers : 40mm)

$31.95

use the contents of this set to change the speed of your existing sets

  • contains: motor, 2 set gears, metal shafts, gearbox and other accessories
  • powered by: 2 x AA batteries (not included)

$11.45



2 IN 1 Gearbox for Wooden Kits
(KNS7)


Price: $12.20

RUNNING MICROBUG-MK127

Attractive bright colored bug-shaped miniature robot. The microbug is always hungry for light, it drives towards it !

Features

  • two open chassis sub-miniature motors
  • adjustable light-sensitivity suits almost any light condition and allows to control it's 'bug-like' behavior
  • LED 'eyes' indicate driving direction
  • stops in total darkness

Specifications

  • power supply: 2 1.5V AAA batteries (not incl.)
  • dimensions: 4.0" x 2.4"




Price: $17.90

CRAWLING MICROBUG-MK129

Attractive bright colored bug-shaped miniature robot. The microbug is always hungry for light, it drives towards it.

Features

  • two open chassis sub-miniature motors
  • adjustable light-sensitivity suits almost any light condition and allows to control it's 'bug-like' behavior
  • adjustable speed
  • choose between two different walks
  • LED 'eyes' indicate driving direction
  • stops in total darkness

Specifications

  • power supply: 2 1.5V AAA battery operation (not incl.)
  • dimensions: 4.3" x 3.5"




Price: $32.20

CRAWLING MICROBUG-MK165

Attractive bug-shaped miniature robot. The microbug is always hungry for light, it drives towards it.

Features

  • two open chassis sub-miniature motors
  • adjustable light-sensitivity suits almost any light condition and allows to control it's 'bug-like' behavior
  • adjustable speed
  • choose between two different walks
  • LED 'eyes' indicate driving direction
  • stops in total darkness

Specifications

  • power supply: 2 1.5V AAA battery operation (not incl.)
  • dimensions: 5.2" x 3.5" x 2.0"

Home Applications


Price: $31.90

K2 Kit 2 LCD Temperature Meter

Introduces 3 1/2 digit LCD and the very popular 7106 IC. This IC has been used in low-cost multimeters for over 13 years. We use it to measure temperature using a ordinary signal transistor as the sensor. Data sheets are provided as is a breadboard area so you can extend the circuit to build your own voltmeter, ammeter, resistance meter or extended-range temperature meter. Takes away the mystery of how multimeters work. Box provided. 9V battery operation.

LCD data sheet. VI302-DP-RC pdf file for Kits 2 and 34.





$27.98

K21 Kit 21 Two Station Intercom

Simple two wire intercom. Each unit with its own speaker, microphone and amplifier (LM386.) Can be modified to a hard wired 'bug'. With 4 strand ribbon cable the power can be sent to the remote 'bug' unit from the receiving unit.

Scan of PCB

Back to top


Price: $32.80

UNIVERSAL TEMPERATURE SENSOR-VM123

Features

  • applications:
    • measure indoor and outdoor temperatures
    • monitor heating and/or cooling of rooms, equipment, etc...
    • monitor temperatures in processes
    • put a temperature readout on your website
    • check your pools temperature...

Specifications

  • range: -20°C (-4°F)... +70°C (+158°F)
  • output: 0..20mA current loop
  • output voltage compliance: 10V
  • one single adjustment
  • 3-wire system (GND, +V and OUT)
  • power supply:
    • 12VDC for 0..5V OUT
    • 15VDC for 0..10V OUT
  • current consumption: 30mA max.
  • dimensions: 55x35x15mm /2.17" x 1.38" x 0.59"



LIQUID LEVEL CONTROLLER-K2639

This multifunctional device is easy to use in a variety of applications : 1) LED control of set fluid level : LOW, MIDDLE, HIGH ; 2) Controller : the relay automatically switches a pump and/or valve to keep the fluid level between the LOW and HIGH marks ; 3) Alarm : if the sensor detects a level which is too high or too low (selectable), the relay will operate a bell or other alarm device.

Specifications

  • power supply: 12-14V AC or 16-18V DC / 100mA

  • relay output: 240V / 3A max.

  • dimensions:

    • controller PCB: 4.1" x 2.4"

    • sensor PCB: 4.1" x 1.0"

Price: $30.00

DUAL ELECTRONIC DICE-K3400

Two fully independent dice. At your choice you can play with one or two dice. Displays are switched off automatically after 30 seconds to save battery power.

Specifications

  • power supply: 8 to 12V DC or 6V AC / 60mA

  • PCB dimensions: 3.0" x 2.8"

Price:$23.60

MULTITONE CHIME- K6600

The number of tones may be selected up to a maximum of three, each of which is output one after the other. This can be used to help locate the place being called. Volume and tone can also be set. The existing bell transformer can be used as a power supply.

Specifications

  • adjustable tone and volume control

  • 1, 2 or 3 tones selectable

  • loudspeaker output: 0.3W / 8ohm

  • power supply: 6 to 9V AC / 0.2A or 4.5V battery (3 x 1.5V AA batteries (not incl.)

  • idle current: less than 10µA

  • dimensions: 2.1" x 2.3"

Price:$29.80

Alarms and Automotive Applications

ELECTRONIC TRANSISTOR IGNITION FOR CARS-K2543

Gives your car the feel of an expensive luxury car. Better starting and smoother running, particularly at very high and very low RPM. Lower fuel consumption, less pollution, lower servicing costs. Drive economically, drive electronically. Only for petrol/gasoline engines. Only for cars with negative ground.

Specifications

  • max. current: 4A

  • connection speed: up to 500kHz

  • PCB dimensions: 2.8" x 1.4"

Price: $26.40

WINDSHIELD WIPER ROBOT OR INTERVAL TIMER-K2599



Up to 3 different time intervals (2 - 10 - 15 seconds) can be selected for the windshield wipers of your car. It can also be used for automatic slide projection.

Specifications

  • relays on PCB: 2 inverters

  • power supply: 12 - 15V DC

  • PCB dimensions: 3.2" x 2.2"

Price: $25.40

DIGITAL TACHOMETER-K2625

For cars or motorcycles with a petrol engine. May be used as a general purpose revolution counter.

Specifications

  • range: 100 - 9900 revolutions/minute

  • 2 digit display

  • easy calibration

  • power supply: 10 - 15V DC / 200mA

  • PCB dimensions: 3.2" x 1.8" + 3.2" x 2.4"

  • front panel dimensions: 2.8" x 3.5"

Price: $33.00

FROST INDICATOR-K2644



Drive more safely in freezing weather. This kit uses a flashing LED to indicate a road temperature close to freezing point ; below that point the LED is on continuously. A reliable temperature sensor with mounting stud is included.

Specifications

  • power supply: 10 - 15V DC / 25mA

  • PCB dimensions: 2.2" x 1.7"

Price: $18.40

ELECTRONIC WATCHDOG-K2655

A circuit that produces a natural sounding barking dog with a sensitive "ear" to everything that comes near it. It is a faithful watchdog, which never sleeps and never has to be taken out for a walk.

Specifications

  • power supply: 2 x 8V AC or 9 - 12V DC / 500mA

  • choice of two different "dog sounds"

  • reacts to surrounding noise with adjustable sensitivity

  • speaker output: 2W at 4ohm

  • PCB dimensions: 5.6" x 3.0"

Price: $43.35

PARKING RADAR-K3502

If you have problems parking then this kit is for you. Using (ultrasonic) sound waves, whose frequency is beyond our range of hearing, we can "measure" a distance. Consequently, a sensor mounted at the back of the car can give an indication of the distance between your car and the car parked behind you or other obstacles (only at the same height as the sensor). When the preset minimum distance is crossed, an audible signal is generated.

Specifications

  • detection range: 5cm - 1.5m (adjustable)

  • detection angle: 5°

  • supply voltage: 10 - 15V DC / 16mA

  • PCB dimensions:

    • sensor: 1.1" x 3.7"

    • base: 1.9" x 4.9"

Price: $31.05

CAR AUDIO AMPLIFIER-K3503

At last a kit that enables you to build an affordable high power amplifier for your car. Thanks to its universal connections, this power amplifier may be connected to any equipment. For trucks, it can be adapted to be supplied from a 24V source. Complete with heatsink and housing.

Specifications

  • output power: 2 x 100W max.

  • power supply: 14.3V DC (10 - 16V DC allowed) / adjustable to 24V DC (20 - 30V DC allowed)

  • double switched mode power supply (PWM) with MOSFET transistors

  • CD/LINE/LS input, selectable

  • frequency response: 10Hz - 100kHz (CD input)

  • input impedance: 47K or 135ohm

  • supplied with housing

  • dimensions: 9.8" x 7.5" x 2.0"

Price: $219.30

CAR ALARM-K3504

The alarm detects sudden voltage drops of the battery when the interior, trunk, or hood lights are switched on. To ensure correct operation, a number of control indications have been included, such as : flashing LED to indicate that the alarm is in standby mode after a set time (after you have left the car). Pre-alarm (built-in buzzer) to indicate that the alarm is activated, so that you will not forget to switch it off. The alarm is easy to switch on and off, either automatically or by means of the ignition switch or a remote control unit.

Specifications

  • detects voltage drops of the battery

  • entry delay time: 2 to 30 seconds with buzzer indication

  • exit delay time: 2 to 180 seconds with LED indication

  • alarm period: 60 seconds with automatic reset

  • power supply: 12V

  • standby current: 25mA

  • relay output: 5A

  • PCB dimensions: 2.4" x 3.9"

Price: $27.80

CAR LIGHT WARNING ALARM-K3505

This head light indicator may be set for one or two functions. To indicate that the head lights (or the side lights) should be switched off after switching off the ignition contact (battery protection). Or to indicate that the head lights should be on once ignition contact is switched on (obligatory in some countries).

Specifications

  • continuously repeated alarm tone for lights ON (may be disabled)

  • repeated alarm tone for lights OUT

  • only 3 wires are required for hook-up

  • supply voltage: 12V DC

  • PCB dimensions: 1.9" x 2.2"

Price:$19.40

ANTI SPEAKER PLOP FOR K3503 CAR AUDIO AMPLIFIER-K3506

Prevent any annoying plop occurring in speakers when switching the K3503 car booster on and off. In addition, it provides protection for the MOSFET transistors and the car battery (monitoring the voltage drop). The entire circuit can be built into the car booster housing.

Specifications

  • soft start of the switched mode power supply

  • switch-on delay of the speakers: ± 2 seconds

  • immediate switch-off of the speakers when switching off the booster

  • voltage monitor: switch off at +/- 10V

  • only suitable for K3503 2 X 100W car booster

  • PCB dimensions: 2.2" x 2.0"

Price: $21.00

REMOTE CONTROLLED CAR ALARM SYSTEM (RF)-K3511

Price: $129.00

This outstanding car alarm is full of potential, able to connect up with and operate a variety of sensors. In addition, the remote control facility (RF) allows the central locking system to be operated together with the alarm.

Features

  • microprocessor technology

  • multi-functional remote control operation

  • audio and visual on/off indicators

  • multifunction dashboard mounted LED

  • automatic reset after alarm

  • adjustable voltage drop (reaction to interior lighting)

  • voltage drop detection active immediately, or after 5 minutes

  • direct alarm trigger input (direct alarm after triggering)

  • warning alarm trigger input (2 triggers within 15 seconds = alarm)

  • warning input can be switched off with the remote control

  • adjustable shock detector (can be switched off with the remote control)

  • detector input for ventilator in order to avoid false alarms

  • contact switches for bonnet and boot

  • internal siren for on/off signal and alarm

  • output for external siren and pager (5A)

  • alarm time: 30 seconds

  • starter interrupter for ignition or diesel fuel pump (15A)

  • special starter motor interrupter relay (30A) supplied

  • switch on protection if contact is on

  • output to hazard lights (2 x 6A max.)

  • output for central locking (100mA)

  • selectable code for remote control transmitter and receiver (8.748 codes)

  • automatically resets in the event of accidental switch off (60 seconds)

  • diagnosis facility to identify a triggered sensor at a later time

Specifications

  • supply voltage: 12V DC

  • consumption: 50mA in standby

  • temperature range: -40 to +185°F

  • battery for remote control unit: 12V type V23GA, V23A (not incl.)



CODE LOCK-K6400

This code lock may be used to switch an alarm (e.g. car alarm K3504) on and off, or to open a door lock. An LED on the operating panel indicates the position of the 'lock'. The code is easy to define. Because the operation panel is completely enclosed, it may be used inside and outside the house.

Specifications

  • more than 3000 codes (4 digits)

  • relay output: 5A / 110V

  • time limit for code entry: ± 5 seconds

  • power supply: 9 - 15V DC or 8 - 12V AC

  • power consumption:

    • output on: 40mA

    • output off: 0.3µA

  • dimensions: front panel : 3.2" x 3.2", depth : 1.6"

Price: $35.80


Price: $12.00

CAR ALARM SIMULATOR-MK126

LED with 'realistic-appearing' flash sequence simulates active car alarm system.

Features

  • activates automatically when the engine is turned off
  • easy to install, just two wires to connect
  • adjustable sensitivity

Specifications

  • low current consumption: 12mA max. (12V only)
  • comes complete with pre-wired LED-holder and two warning labels
  • dimensions: 2.3" x 1.8"



FM Transmitter




$13.89

K7 Kit 7 3V FM Transmitter

The most powerful 'bug' available for its size, 3V supply and number of components. Guaranteed to transmit over 100 meters within buildings and to 500 meters in the open. Easily tunable in the FM band. Greater range at higher voltage and better aerial.

For an excellent introduction to the theory of 'simple' 2 stage transmitters download FM Transmitter Theory 1.2MB



$10.89

K16 Kit 16 FM Telephone Transmitter

Miniature transmitter which attaches in series with one of the two lines to your telephone. Transmits over 200 meters to an ordinary FM receiver. Transmits further if the FM receiver is near the phone line. Tune with ceramic trim cap. Uses the phone line as an aerial and power source.



$13.89

K18 Kit 18 9V FM Transmitter

More powerful FM transmitter 'bug' than Kit 7. Tank oscillator coil built into the circuit board. Can be tuned anywhere in FM band. 9V battery operation. Over 400m range in the open depending on aerial used.

For an excellent introduction to the theory of 'simple' 2 stage transmitters download FM Transmitter Theory 1.2MB

K18 PCB now has 5 pairs of SM pads for SM resistors to be supplied later.



$13.75

K28 Kit 28 Voice Activated FM Transmitter

A sound activated switch and an FM transmitter joined together to make a voice activated FM transmitter. Set the level of sound that it will respond to. Two stage transmitter needs tuning to get best results. Tuning Kit and instructions enclosed. Transmits up to 1 km in the open depending on the aerial used.





$13.89

K32 Kit 32 Three Stage FM Transmitter

Our most powerful FM 'bug' to date. A two stage FM transmitter with an RF transistor (ZTX320) in the output stage. 9V operation. On/off switch mounted on the PCB.

See Kit 32 Report for independent test results on this Kit by Web-surf. For an excellent introduction to the theory of 'simple' 2 and 3 stage transmitters download FM Transmitter Theory 1.2MB





$10.89

K51 Kit 51 Small 2.5cm x 1.5cm 9V Bug

No description.

Remote Control Units

 $49.20



Kit 157 Rolling Code 2-Channel UHF Remote Control
This is state of the art. Up to 15 Tx units can be learnt by one Rx unit.







$55.80



Extra Remote



$16.00

K180 Kit 180 Rolling Code 4-Channel UHF Remote Control

This is state of the art. Up to 15 Tx units can be learnt by one Rx unit. There is a complete description of what rolling code is in the article. For more on using KEELOQ to generate hopping passwords see AN662 and AN665 by Microchip. Do a google.com search on '433.9mhz', 'lipo' for more information about the transmitting band.

$62.40

K181 Kit 181 Rolling Code 10-Channel UHF Remote Control

Kit 181 uses the same Tx/RX pair as Kit 180 but it uses all 10 defined keypress combinations out of the 4 buttons to activate relays. The following keypress combinations give readable outputs: pins 1, 2, 3, and 4 (of course) and the pins 1&2, 1&3, 1&4, 2&3, 2&4, and 3&4 pressed together. A PIC16F628 does ALL the work. It is a perfect demonstartion of how micro-controllers have taken over from cmos logic etc.

Toggle or momentary mode will be determined by keeping the 1 or two buttons depressed for more than 2 seconds and then that relay will stay in that mode until another >2 sec keypress. Small relays are used to save weight and board area.

REMOTE CONTROL BY TELEPHONE-K6501

This kit makes it possible to turn up to three devices on or off over the telephone. It is also possible to check the condition of a switch (open or closed). Example : when you are away on holiday, you may switch the lights on and off from time to time, check the alarm or turn on the heating before returning home. A major advantage of this circuit lies in the fact that audio signals are used to tell whether a specific output has been turned on or off. Operation is protected by a user defined code, which is simply keyed in from the telephone keypad.

Specifications

  • a relay is included for one output: 10A / 250V AC

  • automatic pick-up can be selected for ± 8 or ± 3 rings

  • automatic hang-up if no code is entered within 20 seconds

  • supply voltage: 12V AC / 300mA

  • dimensions: 4.1" x 5.1"

Price: $59.55

THERMOSTAT WITH REMOTE CONTROL VIA THE TELEPHONE-K6502

The thermostat is used as any other one, but with the added facility of choosing the day or night temperature setting by means of a telephone. The remote control facility is operated via the telephone keypad, thus a DTMF type phone is required. From audio signals sent down the line, the user receives a report back on how the thermostat is set. Switching is protected by a security code, set by the user, which is keyed into the telephone in a simple manner.

Specifications

  • separate settings for day and night temperature with LED indication

  • relay output with LED indication: 5A / 240V AC (1200W)

  • telephone pick-up after ± 3 or 8 rings

  • report when the temperature has fallen below 37.4°F

  • automatic hang-up if no code is received within 40 seconds

  • possible security codes: from 000 to 999

  • day temperature: from 57°F to 79°F

  • night temperature setting: from 43°F to 64°F

  • hysteresis (allowed temperature swing): 0.1°F

  • local manual control

  • supply voltage: 110V AC

Price: $129.00

UNIVERSAL RELAY CARD WITH 16 RELAYS-K6714-16

16 relays and screw connectors included ! Power supply transformer is included. Every output of the print can be equipped with a noise suppressor network.

Specifications

  • the relays can be controlled in different ways: direct control from open-collector outputs, TTL or CMOS level

  • DIP switches are included to allow manual activation of the relays in case of maintenance work

  • 16 relay outputs

  • contact: 10A / 28V DC or 125V AC, max. 5A at 230V AC

  • power supply: 125V AC max. 12VA

  • output voltage: 12V / 250mA

  • PCB dimensions: 5.9" x 8.4"

Price:$95.10

UNIVERSAL RELAY CARD-K6714

If you want to switch large electric currents using an electronic control and require control isolation at the same time, then this card is a valuable asset.

Specifications

  • 8 relays included (extendible to 16)

  • the relays can be piloted directly of through open-collector outputs

  • contact: 1 x inverter: 10A / 28V DC or 125V AC, max. 5A at 230V AC

  • relay switch-over contact: max. 5A at 220V

  • output voltage: 12V / 250mA for power supply

  • power supply: 220 or 115V AC / 12VA

  • PCB dimensions: 5.9" x 8.4"

Price:$64.05



10-CHANNEL, 2-WIRE REMOTE CONTROL- K8023

This kit allows you to control up to 10 devices using only 2 wires at a long distance. Microprocessor controlled. Inputs can be push-buttons, switches or open collector outputs from another device. The receiver section provides 10 open collector outputs that allow you to control relays directly. Terminal block connectors for all input and output connections are included. All outputs are provided with LED indication.

Specifications

  • 10 open collector outputs: 50V / 100mA

  • tested to a distance of up to 50m (55 yards) between control- and receiver section

  • operating voltage: single 12-15V AC or DC, 300mA

  • dimensions:

    • control pcb: 2.7" x 2.0" x 0.6"

    • receiver pcb: 4.0" x 2.0" x 1.0"

Price: $34.65

USER DEFINABLE 8-CHANNEL TOUCH PANEL-K8046

Ever wanted your own keyboard with your personal layout and symbols ? Here is the solution : Now simply print YOUR keyboard layout on a transparent foil and make your own keyboard ! The function of each key can be selected (momentary or toggle) and each key is backlit. It is even possible to simulate classic "radio keys" (only one output can be ON, just like a rotary switch). One key can be defined as a preset memory or serve as an "all clear" key. Completing the features of this unique keyboard is a "click" sound when the keys are operated. The output can easily be connected to your own applications.

Features

  • max. 8 self-definable keys

  • LED status indication for each key/output

  • each key can be set up as a toggle key or momentary key

  • soft-touch see-through panel with 8 keys

  • key layout examples are included

  • backlight with dimming function

  • unique key-click feedback

  • optional IR receiver module: IR38DM

  • optional blue backlight: L-934MBC (8 pcs required)

  • "design" mounting frame (bezel) is included

  • easy board-to-wire connectors

  • 4 different functions (jumper selectable):

    • 8 independent keys (toggle or momentary selectable)

    • 8 radio keys (simulation of rotary switch)

    • 4 radio keys and 4 independent keys

    • 1 key is reserved as a memory key or an "all clear"-key

Specifications

  • 8 open-collector switches: max. 50V / 100mA

  • board to wire connectors: 7.9" wire

  • dimensions (frame included): 6.5" x 3.5" x 1.4"

  • keyboard operating force: 1.4 oz. (with R0.8mm test point)

  • keyboard life: 1000000 operations with R3mm rubber

  • power supply: 9V AC or 12V DC / max. 250mA

  • dimensions: 6.5" x 3.5" x 1.4"

Price: $82.20


Price: $16.60

REMOTE CONTROL VIA GSM MOBILE PHONE-MK160

Features

  • turn equipment on and off at any location via GSM mobile phone
  • applications: turn on lighting, heating, open your gate, simulate presence, control animal feeders, activate car alarm, etc...
  • ring detection circuit avoids phone charges
  • no need to open or modify phone, no physical connection to mobile phone
  • works with most GSM mobile phones

Specifications

  • dual operation mode: on/off toggle or on with auto turn-off timer
  • timer settings: 0.5s, 2s, 30s, 1 min, 5 min, 15 min, 30min and 1 hour
  • NO/NC 3A relay output
  • power supply: 12Vdc / 100mA
  • dimensions: 4.0" x 1.7" x 0.9"

Price: $27.80

2-CHANNEL IR REMOTE RECEIVER-MK161

Features

  • two channels with relay output (24VAC/DC 1A max.)
  • ultracompact mode
  • channel and reception indication through LEDs
  • toggle / pulse selection for each channel
  • learn mode for channel ID
  • all settings are stored in EEPROM

Specifications

  • power supply: 12V DC
  • power consumption: 75mA max.
  • dimensions: 1.7" x 1.9" x 0.6"




Price: $22.00

2-CHANNEL IR REMOTE TRANSMITTER-MK162

Features

  • compact 2-button IR keychain remote
  • compatible with most Velleman IR receivers
  • 2 powerful IR LEDs for a range of up to 15m (indoors)
  • 16 channels (allow use of multiple transmitters in one room)
  • easy channel configuration, no jumpers required
  • 'Transmit'-LED

Specifications

  • power supply: 12V (e.g. VG23GA, GP23GA, etc...) (not incl.)
  • dimensions: 2.3" x 1.6" x 0.5"




Price: $20.60

ELECTRONIC STEREO VOLUME CONTROL-MK163

Features

  • IR-controlled electronic volume adjustment
  • controls the volume of line-level audio signals, suitable for PC or hi-fi applications
  • small enough to be built into existing units e.g. CD & DVD players, ...

Specifications

  • stereo line level in/out: 2Vrms max.
  • range: 0dB to -78dB (62 steps)
  • 'mute'-function with auto fade-in
  • volume up/down/mute buttons
  • power supply: 9-12V DC / 100mA
  • dimensions: 3.2" x 1.4" x 0.6"



Interface Systems and Programmers



$42.90

K59 Kit 59. 68HC705P9 Programmer

We developed a programmer for the P9 micro-controller used in our Codepad, Kit 53. We thought there was enough general interest to issue this programmer as a Kit. Top quality components are supplied. Space for 2 ZIF sockets. Double-sided PTH PCB.

Scan of PCB





$41.80

K99 Kit 99 Motorola 68HC705K1 Programmer/Simulator

For 386 & 486 machines only.





$89.60

DIY KIT 117 PICALL Microcontroller PIC Programmer

A continuity tester is one of the most useful pieces of test equipment to have. It is used for testing the electrical continuity between two points. Our tester will "buzz" up to a specified resistance or less. Two on-board resistance ranges available. Full theory of operation given. The user may adjust the resistance ranges to suit his own requirements.

The kit is driven from the Parallel Printer port of a PC using a straight thru M/F 25 pin cable. These are readily available.

There is no software Registration, as a programmed chip is supplied in the kit, and the PC driver software is free.

For volume programming and maximum flexibility the kit requires one on-board wide-slot 40-pin ZIF socket. The software tells you where to place the PIC you are programming. (Note some older designed PIC programmers available like the Warp-13 have 2 or even 3 (!) ZIF sockets on-board. Only one wide-slot 40 pin ZIF socket is necessary with PICALL.) The reason the 40 pin ZIF socket is not included is because these are manufactured in north America while the kit is packed in Hong Kong. Since most kits are sold in Europe & north America it is cheaper if you buy the socket locally.

All software and other documentation is available from Bojan Dobaj's Home Page at picallw.com

For a full list of the devices programmed by Kit 117 visit picallw.com

K117. PICALL for Windows software. V0.10c. november, 2001. 750K. Latest. All the Error Messages are now in Help of the Hardware Settings and Testing.







$58.00

K122 Kit 122 Atmel AVR programmer

To program 20-pin DIP - 90S1200, 90S2313, and 40-pin DIP - 90S4414, 90S8515. Programs at 9600 baud. Parallel mode. With the optional adaptor board you can now program AT90S4434 and AT90S8535. It will not program the 8-pin AVR devices (90S2323, 90S2343).

Scan of PCB

Adaptor board for K122 to program 90S4434/8535.

Underside view of adaptor board

Top view of adaptor board







$58.00

K123 Kit 123. Atmel 89xxxx Programmer

To program

  • 89C1051, 89C2051 and 89C4051

  • 89C51, 89LV51

  • 89C52, 89LV52

  • 89C55, 89LV55

  • 89S8252, 89LS8252

  • 89S53, 89LS53

  • 87F51, 87F52 (otp) support added august, 2000

Two DOS utilities are available for downloading to examine and reorder fragmented hex files which some compilers produce. (Fragmented hex files can choke any serial programming software not expecting it.) hexmap.exe and reorder.exe

term.zip No frills terminal program written by Frank to program Kits 121 122 and 123. Easier than using Hyperterminal. DOS based but will run under W9x.

Scan of PCB







 $89.00

K144 Kit 144 Enhanced PICALL Microcontroller PIC programmer

This is an enhanced K117. It will program some Scenix uC's, Atmel AVR's and EEPROMS. See picallw.com for lists of the uC's it will program.

In addition it has an header for USP programming of PICs and Atmels. A 6-pin header and harness come with the kit.

June, 2002. K144 now supports PIC18Xxxx chips. Get the latest software for PICALL for Windows software. V0.13c. october, 2002.

July 4, 2002. K144 now support programming PIC18Fxxx chips. You must use the latest software for PICALL for Windows software. V0.12c. May, 2002. A small hardware addition is needed for K144. No hardware change is needed for K96.









 $46.80

K149 Kit 149 USB/Serial PIC programmer

*THE KIT DOES NOT INCLUDE ZIF SOCKET

Released 12/2002. A DPST switch switches between USB and serial modes. The kit uses a modern, surface-mount FT232BM presoldered on the solder side of the board..

New chipinfo.dat file with data for 18F452 and 18F252.



 $59.70

K150 USB PIC Programmer WITH ZIF SOCKET

It has a B USB connector put on it as well as a 6 pin ICSP connector.

This Kit is fully assembled







 $13.50

K151 Kit 151 EEPROM Programmer

PC Parallel port programmer for the 24xxx, I2C bus and 93xxx EEPROMS. 8 bit programming mode only. We use a 24C16 Software in the Christmas Tree Kit 103 so that was the main reason we did the kit. A 16 pin ZIF socket is used on-board. The top 8 pins are for the 24xxx; the bottom 8 are for the 93xxx SPI EEPROM's.

Kit 151. eeprog.exe software



 $39.00

Kit 182 USB Flash PIC programmer no ZIF socket

Kit 182 is Kit 128 without the ZIF socket. It is thus a Flash ICSP Programmer operating from the USB port. It will be sold fully assembled as most of the components are surface mount. The board is only 48 x 30mm. There are 4 nylon 10mm standoffs to protect the underside. USB 'B' female connector.

Click on the picture below for more information.



PIC PROGRAMMER BOARD-K8076

This board can program a wide range of Microchip® PIC™ microcontrollers

Features

  • onboard configurable 40 pin. ZIF socket

  • Microcontroller selection using patch jumper

  • easy to use programming PICprog2006™ software included

  • SUBD connector set included

  • minimum system requirements:

    • IBM Compatible PC, Pentium or better

    • Windows™ NT/2000/XP

    • CDROM drive

    • free serial RS232 port required

Specifications

  • power supply: 15V DC, min. 300mA adapter (Ex. PS1508)

  • serial port connector: 9 p. SUBD

  • dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"

Price: $48.30

8 INPUT PROGRAMMABLE MESSAGEBOARD WITH LCD & SERIAL INTERFACE-K8045

Price: $ 49.95

Features

  • add an LCD display to any low-tech application and make it look high-tech !

  • replace up to 9 indicators or lamps by one single backlit LCD

  • recall messages simply by pressing a button

  • inputs accept dry contacts, open collectors and logic levels

  • no programming skills required !

  • store up to 9 sixteen-character messages in non-volatile EEPROM memory

  • 4 operating modes:

    • 1): display the status of all inputs simultaneously

    • 2): display all active inputs

    • 3): display active input with highest priority

    • 4): display text messages in a 'tickertape'-fashion

  • a default message can be entered which is displayed when no inputs are active

  • message transfer software is available from www.velleman.be

  • 1 on-board pushbutton available for your application

Specifications

  • inputs: 8 inputs (24Vmax)

  • display: 16 character 1 line supertwist backlit LCD

  • communication: RS232 serial 2400/N/8/1 no handshaking

  • power supply: 9-12V DC / 150mA adapter or 2 x 9V AC / 150mA transformer

  • dimensions: 4.9" x 2.9" x 1.2"


PIC™ PROGRAMMER BOARD-VM134

Features

  • regularly updated list of microcontrollers through our web site
  • onboard configurable 40 pin. ZIF socket
  • easy to use programming PICprog2006™ software included
  • on board "In Circuit Serial Programming" connector

Specifications

  • power supply: 15V DC, min. 300mA adapter (Ex. PS1508)
  • serial port connector: 9 p. SUBD
  • dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"
  • minimum system requirements:
    • IBM Compatible PC, Pentium or better
    • Windows™98/ME/ NT/2000/XP/VISTA
    • CDROM drive
    • free serial RS232 port required (*)

    Price: $89.93

Light Application


$13.50

K8 Kit 8 Light Alarm

Detects very small amounts of light and sounds the piezo alarm. Put it in your cash box or cupboard. Uses Darlington photo transistor MAL12 (replaced the MEL12 in mid-1998) and 14011 IC. Educational kit.

1 CHANNEL DMX CONTROLLED POWER DIMMER-K8039

Price: $52.05

This kit allows you to control a lamp or group of lamps through a DMX signal. The DMX protocol was developed by USITT in 1986 with the purpose of controlling dimmers, scanners, moving heads and other lighting devices with simple wiring. It is mainly being used in theatres and discos, but you can use it in any place where a central or automated lighting is needed.

Features

  • suitable for resistive loads like incandescent lamps and mains voltage halogen lighting

  • system addressability: 512 unique addresses, selectable with DIP switch

  • status LED for power and error detection

  • toroidal filtering for low noise (according to EN55015)

  • stand alone "test" mode

  • control source: DMX-512, 3 pin XLR socket included

Specifications

  • load capacity: max. 1000 W @ 230V (5A) or 500W @ 115V

  • power Input: 115/230 VAC

  • size: 150 x 60 x 45mm / 5,9 x 2,36 x 1,77"

DMX CONTROLLED RELAY SWITCH-K8072

Price: $41.85

This Kit allows you to control a relay by means of the well-known DMX512 protocol. This protocol was developed by USITT in 1986 to control dimmers, scanners, moving-head spots and other lighting devices with a simple wiring.
In some cases, a simple ON/OFF selection is desired. This is where this K8072 comes in. It is actually a bus-controlled power driver. The relay will be activated when the DMX value of the set channel equals 140 or more and turns off when the value is 120 or less.

Features

  • system addresses: 512 unique addresses, DIP switch settable

  • LED indication for power supply, relay output status and error situation

  • "Safe DMX data stream" mode reducing interference to a minimum

  • "Relay hold" function in case of DMX signal loss

  • control: DMX-512, 3-pin XLR plug (incl.)

Specifications

  • switching capacity: 8A

  • supply voltage: 12VDC non-regulated

  • power consumption: max. 100mA

  • dimensions: 105 x 60 x 30mm / 4,1 x 2,4 x 1,2"

POWER DIMMER, PUSH-BUTTON CONTROLLED (1KW@230V)-K8038

Price: $34.65

Features

  • powerful high-quality dimmer, suitable for incandescent lamps, mains voltage halogen lighting and low voltage halogen lighting in combination with a conventional (wire wound) transformer

  • easy push-button operation for dimming of light sources.

  • phase control can be disabled

  • non-volatile memory for last set light intensity

  • lots of safety features to make lamps last as long as possible, such as "oftstart" and automatic turn-off after 12h or after 20min at too low intensity

  • transformer protection in case of defective light sources

  • LED status indication

Specifications

  • suppression of radio & TV interference according to EN55015

  • operating voltages: 110-125V or 220-240V AC (50/60Hz)

  • max. load: 1000W/230V or 500W/115V (5A)

  • max. phase shift with inductive load: 30°

  • dimming speed: ± 5 sec.

  • PCB dimensions: 3.5" x 2.9" x 1.6"

  • ambient temperature: 10°C to 40°C

MULTIFUNCTIONAL DIMMER-K8028

Price: $34.65

Features

  • microcontroller technology

  • 13 different functions: impulse switch, staircase light control, slow ON/OFF dimmer, interval timer, speed adjustment for fans, etc…

  • suitable for both resistive and inductive loads (light bulbs, high-voltage halogen lighting and low-voltage halogen lighting with ferromagnetic transformer)

  • "Soft Start" prolongs the life of the bulbs

  • an advanced security system with fault indication automatically deactivates the module if the load or no-load behaves too inductively

  • can be operated from several locations, simply by the parallel connection of push buttons

  • 2 delay times (anywhere between 5 sec. to 2 hours each) can be programmed through the learning mode

  • memory is protected against power failures

  • equipped with fuse and key for function selection

  • equipped with a mains suppressor according to EN55015 norms

Specifications

  • supply voltage: 110-125V or 220-240V AC, 50 or 60Hz

  • automatic detection of mains frequency: 50 or 60Hz

  • max. load: 2.5A (300W / 120V ; 600W / 230V)

  • dimensions: 3.9" x 3.2" x 1.4"

4 CHANNEL RUNNING LIGHT-K8032

The running light module is the perfect addition to your existing system if you are looking to create the kind of effects used in a disco. The speed of this module can be adjusted manually. All the outputs are equipped with LED indication.

Specifications

  • suppressed according to EN55015

  • adjustable speed for the switching of the charge

  • led indication

  • AC power: 110 to 240VAC

  • max. load per channel: 450W (240VAC) / 230W (115VAC)

  • speed adjustable between: 0.2 and 3Hz

  • dimensions: 3.9" x 3.2" x 1.4"

Price: $34.65

POWER BLINKER-K8033

This blinking module was designed for the activation and deactivation of a load (e.g. lighting) in order to obtain a blinking effect. The ON and the OFF duration can be adjusted separately. The blinking module is suited for both resistive and slightly inductive loads. This blinking module is ideally suited for steering e.g. disco lights, safety signs, light bulbs, ferromagnetic transformers for halogen lighting, etc ...

Specifications

  • noise suppressed according to EN55015

  • adjustable speed

  • led indication

  • AC power: 110 to 240V AC

  • max. load: 500W (240V AC) / 250W (115V AC)

  • ON-time adjustable between: 50ms and 2.5s

  • OFF-time adjustable between: 0.5s and 15s

  • dimensions: 3.9" x 3.2" x 1.4"

Price: $25.20

STROBOSCOPE-K5300

Flashing light effects for discos. Make your own snapshots and "lightning" light effects. Flash frequency adjustable from 2 to 20Hz.

Specifications

  • power supply: 110V - 120V AC

  • PCB dimensions: 3.4" x 2.6"

Price: $27.60

LIGHT COMPUTER-K5201

Sixteen different programs and seven outputs make this light computer a unique showpiece. This kit can find applications in party lighting, discotheques, advertisement lighting, signaling, etc. To be able to view the programs directly, each output is provided with a LED. The complete circuit can be installed so that all operations and LEDs are available from the front panel. To enhance the spectacle further, an unlimited number of circuits can be connected together to work synchronously. Moreover, two programs are provided which are specially adapted to operate two light computers in cascade.

Specifications

  • 7 triac outputs: 1.5A max.

  • supply voltage for the lights: 24VAC to 240VAC

  • supply voltage of the circuit: 7.5 - 9VAC / 250mA

  • 16 programs

  • speed controllable

  • input for external clock

  • PCB dimensions: 5.3" x 3.1"

Price: $59.55

PUSHBUTTON CONTROLLED DIMMER-K8024

Price: $16.20

Easy pushbutton up/down control of light sources. A brief push toggles on/off, while continued pushing engages dimming action / memory function maintains preferred level.

Features

  • soft-start function

  • suitable for low voltage halogen lighting

  • with fuse and power indicator

Specifications

  • operating voltages: 110-125 or 220-240V AC 50/60Hz

  • max. load: 3.5A (375W/110V ; 750W/220V)

  • noise suppressed according to EN55015

  • dimming speed: approx. 3.5s

  • dimensions pcb: 2.4" x 1.9" x 1.5"



LIGHT SENSITIVE SWITCH-MK125

Switch-on at dusk, turn off at dawn, fully automatic.

Features

  • wide-range adjustable sensitivity
  • delay circuit avoids cycling

Specifications

  • relay output: NO/NC 24V/5A max.
  • power supply: 12V DC
  • with adapter-connector
  • dimensions: 2.6" x 2.0"

Price: $ 9.80

Motor Speed Controllers







$30.25

K67 Kit 67 DC Motor Speed Controller

Control the speed of any common DC motor rated up to 100V (5A). Operates on 5V to 15V. Uses NE556 to pulse-width modulate a high current switching power transistor, TIP122. In this way motor torque is maintained. Adjustable speed control. Box mounted.



 $32.50

Kit 166 Bidirectional DC Motor Speed Controller

This kit allows controlling the speed of a DC motor in both the forward and reverse direction. The range of control is from fully OFF to fully ON in both directions. Normally, switches are used to change the direction of rotation of a DC motor. Change the polarity of the applied voltage and the motor spins the other way! However this has the disadvantage that a DPDT switch has to be added to change the polarity of the applied voltage. Now you have two things to control the motor – a direction switch as well as the speed control.

Also, it is not a good idea to suddenly reverse the voltage on a DC motor while it is spinning. It can cause a current surge that can burn out the speed controller. Not to mention any mechanical stress it can cause as well. This kit overcomes both these problems.

For more information click on the picture.

Power Supplies and Chargers


Price: $21.41

K4 Kit 4 Basic Power Supply Module

Batteries soon become an expensive way to power your electronic kit and electronic games. This is a basic power supply in a box using two 7805 regulators. Input up to 20V AC from a transformer or power pack. Two regulated outputs are available - one fixed at 5V, the other variable. Good introduction to three terminal regulators.





$13.19

K60 Kit 60 Regulated Power Supply

Kit accepts an unregulated AC or DC input. The user supplies a standard 3 pin voltage regulator from 5 volts (using a 7805) to 24 volts (7824). The full range of possible regulators is: 7805, 7806, 7808, 1810, 7812, 7815, 7818 & 7824. Large heat-sink provided. PCB = 64mm x 40mm (2 1/2" x 1 1/2")





$18.97

K83 Kit 83 Kit 83 Universal Power Supply

Put in your own 78xx and 79xx 3-pin regulators (TO-220 type) to give fixed positive and negative voltage outputs which you want for your project. Supplied with 2 small heatsinks. Requires centre-tapped AC voltage source.

Dimensions = 78mm x 43mm







$15.40

K68 Kit 68 Power Supply Module using LM317T

This is a basic adjustable voltage power supply using the popular three pin regulator, LM317T. You can select any voltage between 1.5V and 30V using a potentiometer. The LM317T is rated at 1.5A so you must use a larger heat sink when drawing high currents.







$20.90

K114 Kit 114 Dual Unregulated Power Supply

Four on-board 100V, 3A diodes plus 2200uF/50V electrolytics to provide an unregulated power supply from a center-tapped transformer.



Kit 124 documentation

Kit 125 documentation

K124

$21.45


K125

$21.45

Kit 124 & Kit 125. Compact positive (K124) and negative (K125) adjustable power supply

+/- 1.5V to 35V depending on input power source. On-board heatsink.





 $13.50

K135 Kit 135 Step-Up DC to DC Converter

Designed for countries (like most of Europe) which only have power supplies to 12VDC. This Kit increases the voltage to 16.5VDC which is needed for out PIC programmers - Kits 81 96 117 and 119.

 $16.68





K186 Kit 186 Power Amplifier D.C. Supply

This is a DC power supply board designed for our Kit 106 audio power amplifier. It is also suitable for any power amplifier module or circuit requiring a positive and negative rail voltage of up to 45 Volts per side. The output voltage and current will depend on the transformer chosen, and this is not supplied with the kit. Never use a transformer larger than 35V-0-35V, as the capacitors voltage rating will be exceeded.





1A POWER SUPPLY KIT-K1823

This small power supply provides a regulated voltage, adjustable between 1.5 and 35 volts at 1 Amp. With the LM317 regulator remarkably better ripple and regulation characteristics are given than with conventional regulators. Current limiter and thermal overload protection are included in the IC. Supplied without heatsink.

Specifications

  • output current: 1.5A max.

  • max. dissipation: 15W (cooled)

  • max. input voltage: 40V DC

  • PCB dimensions: 2.1" x 2.1"

Price: $15.00

UNIVERSAL POWER SUPPLY 5-14 V DC/1A-K2570

Suits all Velleman kits requiring a regulated power supply between 5 and 12V DC, and no more than 1A.

Specifications

  • input voltage: 7-16V DC / 1A

  • output voltage: 5-14V DC, regulated

  • output current: max. 1A

  • power limitation and thermal overload protection

  • max. dissipation: 7W

  • PCB dimensions: 3.0" x 2.4"

Price: $21.00

3 TO 30V/ 3A POWER SUPPLY-K7203

Price:$ 49.00

This kit is meant as an auxiliary or as a permanent power supply for all common Velleman kits based on a stabilized DC voltage between 3 and 30V provided that the consumption does not exceed 3A. Of course this power supply unit can also be used for other purposes. Be replacing the trimmer by a potentiometer, it may even be used as an adjustable power supply unit. Supplied with heatsink.

Specifications

  • output voltage: adjustable from 3 to 30V, stabilized

  • output current: max. 3A

  • output ripple voltage: 0.5mV

  • short-circuit stable

  • overload protected

  • input voltage: 9 to 30V AC (depending on the desired output voltage)

  • transformer not supplied

  • dimensions: 5.1" x 3.6" x 2.0"

LOW COST BATTERY CHARGER-K7302

Price:$ 13.80

Charges NiCd or NiMH batteries. Ideal for car use. Transforms a mains adapter in to a charger (adapter socket included). Charge cellular phone, toys, portables, video batteries, ... Selectable charge current. LED charge indication.

Specifications

  • charge current: 50mA, 100mA, 200mA, 300mA, 400mA (selectable)
  • supply voltage: from 6.5V to 21V (depending on used battery)
  • supply current: same as charge current
  • power supply polarity protected
  • LED function indication
  • dimensions: 1.6 x 2.4"

Stepper Motors Controllers



$39.90

K94 Kit 94 Digital Rotary Control of a Unipolar Stepper Motor

This kit uses a Grey switch aka bit switch, to single step a unipolar tepper motor in either direction. Uses a PIC 16C54 plus UCN5804 stepper driver IC. PCB is 4 in square, single sided.





$28.00

K102 Kit 102 Four servo Motor driver

Using a PIC 16C71, a crystal, 8 resistors & 4 capacitors this kit will independently control up to 4 servo motors. We do not supply the potentiometers or servo motors. (We used a Futaba FP-S148 for out tests.) 5V DC power supply required. Full instructions provided.





$43.90

K109 Unipolar Stepper Motor Driver Kit

Drives any 5, 6 or 8 lead unipolar stepper motor. Based on the UCN5804 IC. All features of this IC (direction, on/off, pins 9 & 10) are brought out to SPDT PCB-mounted switches. Pulses from a 555 setup as an astable oscillator are used to rough position the motor. Switch to manual single-step mode for final positioning using a tact switch. 4 LED's give visual indication that step has been made. Three run modes supported. Full explanation.





$32.45

K113 Kit 113 Two Stepper Motors Driven from a PC

Connects to the PC parallel port & will drive two stepper motors up to max. 3A each. All contained in an RS232, extended D-shell case. Software will accept 4 inputs from external switches. Software will also single step motors. Three run modes supported. All components supplied except the stepper motors.

 $27.50



Kit 158, Bi-polar Stepper Motor Driver kit

This kit will drive a bi-polar stepper motor driver using
externally supplied 5V levels for steping and direction.
These usually come from software running in a computer.

Click on the picture below for more information.

$28.00

K179 Kit 179 Unipolar Stepper Motor Driver


$39.00


Kit 187 Stepper Motor Drive

The Stepper Motor Chopper Driver is a Bipolar Stepper Motor Drive with easily adjustable current control up to 2A, based on the SGS-Thompson L297 and L298 stepper motor controller and driver IC’s.

Stepper motors are rated by current and and not by voltage.  A chopper driver because it is  switching on and off current allows a set current to be fed to the coils and not be dependent on the voltage of the power supply.  The Chopper Driver also allows for the use of higher voltage power supplies (up to 36V) to overcome the effects of the inductance of the coils giving better performance and a higher top speed.

Logic Probe Kits



$17.05

K24 Kit 24 Logic Probe

This is the most important piece of equipment for testing and measuring digital equipment. It is usually used in fault finding and testing but can also assist in design work and to find out how digital equipment works. Switch for either TTL or CMOS. Our own modern design using a PUT. Includes detection circuit for very fast pulses. Gives visual (3 LEDs) and audio (piezo buzzer) response.

Panel Meter Kits



$32.89

K34 Kit 34 3 1/2 Digit LCD Panel Meter (using 7106)

Make this general purpose 3 1/2 digit LCD panel meter into your own voltage or current meter or custom-make it to measure voltage input from a transducer. Full details are given in the documentation. Uses the very popular 7106 IC. The LCD section of the PCB may be cut off and mounted separately.





 $26.40

K127 Kit 127 3 1/2 Digit Panel Meter

A double-sided board designed to eventually replace Kits 2 and 34.

Function Generator & Oscillator



$14.89

K23 Kit 23 Op amp Function Generator

Good value-for money & simple circuit to generate square, (pseudo) sine and triangle waveforms in the audio range. Uses quad opamp LM348.





$18.21

K111 Kit 111 Square Wave Oscillator

Simple circuit to generate square waves of approximately 1Hz 10Hz 100Hz 1KHz 10KHz & 100KHz.

Radio Kits





$21.08

K63 Kit 63 One Chip AM Radio

Complete AM radio on a PCB. Tuned radio frequency front-end, single chip RF amplifier & detector and two stages of amplification of the audio signal into a speaker. All components supplied. Coil prewound. Excellent for schools. Uses MK484 radio IC.

FM RADIO-MK118

Features

  • double fun: building and listening !
  • easy to assemble: no coils to wind
  • one single adjustment
  • pre-assembled and tested FM front end
  • receives the complete FM band: 88-108 MHz
  • with ON/OFF switch, volume control and LED indicator

Specifications

  • power supply: 12V DC / 100mA (adaptor jack provided)
  • dimensions: 4.8" x 3.3"

Price: $28.20

Strobe Light Kits





$22.80

K14 Kit 14 110V & 240V Mains Powered Strobe Light

Kit contains Xenon Flashtube as found on aircraft, camera flash units, signal beacons and disco lights. Adjust to flash from 1 every three seconds to 3 flashes per second.

CAUTION: Connects directly to mains power supply. Must be put in a suitable enclosed box before using. Two PCBs for different mains voltage.





 $24.10

K162 Kit 162 6V DC Xenon Flasher

6V DC Xenon Flasher. Uses on-board EE16 transformer. Uses a neon to trigger the Xenon tube flash.





 $24.10

K163 Kit 163 12V DC Xenon Flasher

Uses a sidac instead of a neon tube to trigger the flash. Sidacs represent a unique set of thyristor qualities. The sidac is a bi-directional voltage triggered switch. Some characteristics of this device include a normal 95 to 330 volt switching point, negative resistance range, latching characteristics at turn-on and a low on-state voltage drop. One cycle surge current capability up to 20 amps makes the sidac an ideal product for dumping charged capacitors through an inductor in order to generate high-voltage pulses. Applications include light controls, high-pressure sodium lamp starters, power oscillators and high-voltage power supplies

Voice Recorder Kits





$42.90

K64 Kit 64 120 Second Message Recorder

Record as many messages as you can in this modern, non- volatile, combined audio processing & memory chip from Information Storage Devices (ISD25120). One button to START/PAUSE & a second button to RESET.





 $36.50

K146 Kit 146 40 second message recorder with looping option

40 second message recorder with looping option. This kit will take any ISD DIP chip from ISD2540 to ISD25120. A switch will loop the first message continuously.



Email us if you have any questions.

Place an order

A1 Electronic Parts
196 North Queen St.
Toronto, Ontario
M9C 4Y1
Tel: (416) 255-0343
Fax: (416) 255-4617
