3mm Super Bright LED's Brightness rating @ 20mA |
||||
$ 0.60 / each | $ 50.00 / for 100 | $ 230.00 / for 500 | ||
(Red) | 800-1000MCD | |||
(Yellow) | 1000-1200MCD | |||
(Green) | 2000-3000MCD | |||
(Blue) | 800-1000MCD | |||
(White) | 1000-2000MCD | |||
5mm Super Bright LED's Brightness rating @ 20mA |
||||
$ 0.60 / each | $ 50.00 / for 100 | $230.00 / for 500 | ||
(Red) | 5,500MCD | |||
(Yellow) | 4,300MCD | |||
(Green) | 6,500MCD | |||
(Blue) | 5,000MCD | |||
(White) | 14,000MCD | |||
10mm Super Bright LED's Brightness rating @ 20mA |
||||
$ 1.00 / each | $ 90.00 / for 100 | $ 350 / for 500 | ||
(Red) | 6,000~7,000MCD | |||
(Yellow) | 3,000~4,000MCD | |||
(Green) | 20,000~30,000MCD | |||
(Blue) | 4,000~5,000MCD | |||
(White) | 15,000MCD | |||
5mm Flashing LED's (Red / Green) 3 VDC Requires no external circuitry. Easily driven by TTL or C-MOS (3-12VDC) 1.6MCD |
||||
Price | Paypal | Price | Paypal | |
(Red) | $ 1.25/ each | |||
(Yellow) | $ 1.25/ each | |||
(Green) | $ 1.25/ each | |||
(White) | $ 2.00/ each | |||
(Red / Green) | $ 2.00/ each | $ 17.00/ for 10 | ||
(Red / Green / Blue) | $ 2.50/ each | $ 22.50/ for 10 |
All LED`s require a resistor in series to limit
the current to the required specification (usually 20mA)
Use ohm`s law to calculate the value of the resistor required. Most LED`s have a
voltage drop of 2 volts.
Blue & white LED`s are 3.5-4 volts
V = IR (volts = current (amps) x resistance)
For a 12 VDC supply voltage @ 20mA the required resistor would be:
10 (volts) / .02 (amps) = 500 ohms
LED`s are suitable for DC ONLY
3mm Standard LED's
Brightness rating @ 10mA |
||
Part Number | Paypal | |
55-532-0 (Red) | 3.0MCD | |
55-533-0 (Orange) | 3.5MCD | |
55-534-0 (Yellow) | 18MCD | |
55-535-0 (Green) | 18MCD | |
5mm Standard LED's
|
||
Part Number | Paypal | |
55-552-0 (Red) | 30MCD | |
55-553-0 (Orange) | 30MCD | |
55-554-0 (Yellow) | 30MCD | |
55-555-0 (Green) | 30MCD | |
5mm High Brightness LED's |
||
Part Number | Price | Paypal |
LIR1 (Infra Red) | $ 0.96 | |
LUV1 (Ultra Violet) | $ 0.96 | |
BI-Color LED's
2-lead dual color LED $ 0.50/ each |
||
Part Number | Paypal | |
55-582-0 (Red/Green) | 2.2/3.5MCD | |
3 mm 3-lead dual color LED |
||
Part Number | Price | Paypal |
SSL-LX3059GIW-CA (Red/Green) | $ 0.50 | |
5mm TRI-Color LED's 3-lead dual color LED $ 0.40/ each |
||
Part Number | Paypal | |
55-592-0 (Red/Green) | 2.2/2.5MCD | |
5mm Round with flange Full color RGB
LED |
||
Part Number | Price | Paypal |
5MM RGB (Red/Green/Blue) | $ 1.00 | |
3mm R/A LED's Brightness level @ 10mA $ 0.30/ each |
||
Part Number | Paypal | |
55-542-0 (Red) | 3.2MCD | |
55-545-0 (Green) | 15MCD | |
5mm R/A LED's Brightness rating @ 10mA |
||
55-562-0 (Red) 3.2MCD $ 0.36 |
55-564-0 (Yellow) 5.0MCD $ 0.48 |
55-565-0 (Green) 5.7MCD $ 0.48 |
Rectangular LED's |
||
Part Number | Price | Paypal |
55-602-0 (Red) | $ 0.12 | |
55-603-0 (Orange) | $ 0.24 | |
55-604-0 (Yellow) | $ 0.18 | |
55-605-0 (Green) | $ 0.18 |
LED Holders | |
3mm Mounting Bezel 3mm plastic mounting bezel (1piece) 55-530
|
5mm LED Holder Plastic 2 piece panel mount holder for 5mm LED's. 55-550
|
5mm LED Holder (Concave) Plastic 1 piece panel mount holder for 5mm LED's 55-550A |
5mm LED Holder (Convex) Plastic 1 piece panel mount for 5mm LED's 55-550B |
