Special
MCH-3002
$179.99
Now: $99.99
| Frequency range | 0.1 Hz~2MHz |
| Output waveforms | sine, Triangle, square, ±Ramp, ±Pulse |
| Output impedance | 50Ω ±10% |
| Output Amplitude | Not less than 20Vp-p(open circuit) |
| DC Voltage | 0~±10V continuously adjustable |
| Symmetry range | 90:10-10:90 |
| Rising edge of square | Less than 100ns |
| Sine characteristic | |
| Distortion | Less than 1% at 10Hz-100KHz |
| Frequency response | 0.1Hz~100KHz less than ±0.5ns 100KHz~2MHz less than ±1dB |
| TTL / CMOS output | |
| Level | TTL low level less than 0.4V in pulse wave, high level less than 3.5V CMOS low less than 0.5V in pulse wave, high level 5V~14V continuously variable |
| Rising time | |
| VCF input | Less than 100ns |
| Input voltage | -5V~0V±10% |
| Max. volt-controlled | 1000:1 |
| Input signal | DC-1KHz |
| Frequency counter | |
| Measuring range | 1Hz~30MHz |
| Input impedance | Not less than 1MΩ/20pF |
| Sensitivity | 100mVrms |
| Max. input | 150V(AC+DC) |
| Input attenuation | 20Db |
| Accuracy | Less than 0.003%±1digit |
| Dimension | 310(W) ×100(H) ×260(D)mm |
| Weight | 4Kg |
Arbitrary Waveform / Function Generator
SM-4040
$390.00
Features:
* High resolution, accuracy and stability
* VFD display and rubber keypad allow easy
operation
* Various Waveforms suitable for many
applications
* Wide range of Sweep freq, start and stop
freq. can be set independently
Specification:
Waveforms |
|
| Main Waveforms | Sine, Square (Only sine is available above 40MHz) |
| Waveform Length | 8-16000 points |
| Amplitude Resolution | 12bit |
| Sampling Rate | 200MSa/S(≤80MHz) |
| Built - in Arbitrary | Triang,+Ramp.+Pulse, Rise/fall exponential, Rise/fall logarthm,Gauss noise, Cardiac, SIN(X)/X, DC. |
| Waveform Length | 8-16000 points |
| Amplitude Resolution | 10 bits |
| Sampling Rate | 10MSa/S(≤80MHz) 20MSa/S(120MHz) |
Arbitrary Waveforms |
|
| Waveform Length | 8-16000 points |
| Amplitude Resolution | 10bit |
| Sampling Rate | 10MSa/S(≤80MHz) 20MSa/S(120MHz) |
| Memory | 6*4k |
