Home < Products < Multimeters



Multimeters


Analog-meter Digital multi-meters       LCR-meter




Pocket Size Digital Multi-meter


MCH 830LN

$24.00

3 1/2  Digits LCD Display, max reading 1999

Function Range

 Accuracy

DC Voltage 200mV, 2V,20V,200V,600V ± (0.5% + 2)
AC Voltage 200V,600V ± (1.2% + 10)
DC Current 20uA,200uA,2mA,20mA,200mA,10A ± (1% + 2)
Resistance 200Ω,2KΩ,20KΩ,200KΩ,2MΩ ± (1% + 5)
Included accessories Test leads, 9V (6F22) Battery
Weigh 140g ( included battery and holder)
Size 105 x 60 x 27 mm





Digital Multi-meter

DT 830D

$19.99




Function Range Resolution Accuracy
DC Voltage 200mV 100uV ± (0.5% of rdg +3D)
2000mV 1mV ± (1.0% of rdg +5D)
20V 10mV
200V 100mV
1000V 1V ± (1.2% of rdg +5D)
AC Voltage 200V 100mV ± (1.2% of rdg +10D)
750V 1V
DC Current 200uA 100nA ± (1.8% of rdg +2D)
2000uA 1uA
20mA 10uA
200mA 100uA ± (2.0% of rdg +2D)
10A 10mA ± (2.0% of rdg +10D)
Resistance 200Ω 100mΩ ± (1.0% of rdg +10D)
2000Ω 1Ω ± (1.0% of rdg +4D)
20kΩ 10Ω
200kΩ 100Ω
2000kΩ 1kΩ
Included Test leads, 9V (6F22) Battery
Weight ~ 72g
Size 125 x 70 x25mm








Digital Multi-meter


DT 9205P

$69.00

Function Range Accuracy
DC Voltage 200mV/2V/20V/200V ± (0.8% +5)
1000V
AC Voltage 2V/20V/200V ± (1.2% +5)
750V
DC Current 2mA / 200mA ± (0.8% +5)
20A ± (2.0% +1)
AC Current 2mA / 200mA ± (0.8% +10)
20A ± (2.5% +10)
Resistance 200Ω ± (0.5% +10)
2kΩ/20kΩ/200kΩ/2mΩ/20mΩ ± (0.8% +3)
200mΩ ± (5.0% +10)
Capacitance 20nF/200nF/2µF/20µF ± (4.0% +20)
  200µF ± (5.0% +20)
Crystal triode hFE test hFE
Included Test leads,  9V (6F22) Battery
Weight ~ 250g
Size 188 x 88 x39 mm









Pocket Size Analog Multi-meter


M213
Was  : $16.00
Now $9.99




* Mirrored scale reduces errors due to parallax
* 13 versatile ranges
* 2 k Ω / V DC / AC sensitivity
* Recessed input terminals for safe use
* Fuse & diode protection



Function Range
DCV 10/50/250/500V
ACV 10/50/250/500V ( optional: max. to 1000V )
DCA 500µ / 50m / 250mA
OHM x 10, x 1k Ω ( optional: x 1k Ω only or x 10, x 100, x1k Ω )
dB -10 ~ +62dB
Accuracy ±5% F.S.
Included Test leads, 1.5V x 1  ( AA  ) Battery
Weight ~90g
Size 90 x 60 x32 mm








Analog Multi-meter

ET-1043


$29.00




* A large and bright meter with a scale length of 80 mm and
   its sensitivity of 44µ A at full scale.
* Series capacitor terminal   (Out Put) blocks DC to enable
  measurement of only AC  components.
* Continuity check with buzzer soun
* Fuse protection



Function Range
DC Voltage 0.1/0.5/2.5/10/50/250/1000 V  ±3%f.s.
AC Voltage 10/50/250/1000 V ±4%f.s.
DC Current 50µ/2.5m/25m/250mA ±3%f.s.
Resistance X1/X10/X100/X1K/X10KΩMAX±3% of arc.
dB -10dB~+22dB
 LI 150µ/1.5m/15m/150mA
 hFE 0~1000
Included Test leads, 1.5V x 1  ( AA  ) Battery
Weight ~250g
Size 150 x 100 x36 mm










LCR  Digital Multi-meter


VC 6243A
Was : $59.00
Now $52.00




Function Range
Capacitance 200p/2n/20n/200n/2u/20u/200uF±2.5% + 5, 2000uF±5% + 5
Inductance 200uH±3% ± 5, 2m/20m/200m/2H±2.5% ± 5, 20H±5% ± 5
Resistance 200/2K/20K/200KΩ ±0.8% ± 5, 20MΩ ±2% ± 5
Included Test leads,  9V (6F22) Battery
Weight ~317g
Size 190 x 91 x 40mm
